Zemic ATEX Compression Load Cell | 10 Ton, OIML C3, IP68, Stainless Steel

9999.000

GST 18% Inclusive Price : 11798.820

Prices Inclusive of Taxes

Brand : Zemic

Item Code : BM14A

Availability : In stock

Delivery is available on or before Saturday,18 Apr

Delivery Options:

Delivery :

Qty:

Minimum Buy Qty :50

Add to cart Buy now

Download Datasheet

Save Extra with offers

Get Cashback
Get GST invoice and save up to 18% on Business Purchases.

Registered users will receive business(GST) invoice with your company name and GST number.

Zemic ATEX Certified Compression Load Cell: Hazardous Area Precision for Hopper and Silo Weighing
The Zemic Compression Load Cell sets the standard for safety and accuracy in bulk material weighing within explosive atmospheres. With dual ATEX and OIML R60 C3 certifications and a combined error of ≤0.020%, this load cell delivers trade-approved precision while meeting the strictest safety requirements for hazardous environments. Its current calibrated and hermetically sealed design ensures intrinsic safety and long-term stability in challenging industrial settings.
Engineered from Stainless Steel with superior IP68 protection, this 10-ton compression load cell withstands complete immersion and extreme temperatures from -35°C to +65°C. Featuring a robust 450±5Ω input and 480±5Ω output resistance with high insulation resistance (≥5000 MΩ), it guarantees reliable performance for critical hopper and silo weighing applications where both accuracy and operational safety are paramount.

Key Features & Technical Advantages:
• Dual Safety & Precision Certification: ATEX certified for hazardous areas and OIML R60 C3 certified for trade-approved accuracy with ≤0.020% combined error.
• Current Calibrated Safety: Specifically designed for stable, safe operation in potentially explosive atmospheres with electrical interference concerns.
• Superior Sealing & Protection: Hermetically sealed with IP68 rating ensures complete protection against dust, moisture, and continuous water immersion.
• Exceptional Signal Integrity: High-precision 2.0±0.002 mV/V output sensitivity with excellent insulation resistance for accurate signal transmission in noisy environments.
• Robust Temperature Performance: Minimal temperature effects on zero (≤0.015%/°C) and output (≤0.011%/°C) across -10°C to +40°C compensated range.
• Extended Cable Flexibility: Long 20-meter cable facilitates installation in large-scale industrial setups and remote hopper locations.
• High Overload Safety: 150% maximum safe overload and 300% ultimate safe overload capacity for demanding bulk material applications.

Technical Specifications:
Parameter Specification
Model Compression Series
Brand Zemic
Type Compression Load Cell
Capacity 10 Ton
Material Stainless Steel
IP Rating IP68
Certifications ATEX, OIML R60 C3
Calibration Current Calibrated
Sealing Hermetically Sealed
Combined Error ≤0.020%
Creep Error (30 min) ≤0.016%
Output Sensitivity 2.0 ±0.002 mV/V
Temperature Effect ≤0.015%/°C on Zero, ≤0.011%/°C on Output
Operating Temperature -35°C to +65°C
Compensated Range -10°C to +40°C
Maximum Safe Overload 150% FS
Ultimate Safe Overload 300% FS
Input/Output Resistance 450±5Ω / 480±5Ω
Excitation Voltage 5-12V DC (Max 18V DC)
Insulation Resistance ≥5000 MΩ at 50V DC
Load Cell Intervals 3000 (nLC)
Cable Length 20 meters
Primary Application Hopper & Silo Scales in Hazardous Areas

Recommended Applications:
• ATEX certified hopper and silo scales
• Bulk material weighing in chemical plants
• Explosive atmosphere storage vessel monitoring
• Pharmaceutical powder and granule weighing
• Food processing in hazardous dust environments
• Hazardous material batching systems
• Industrial sites requiring explosion-proof compression weighing
